- DIP
L201204 Serie
• Alloy Powder based DIP Inductor with lower core loss.
• Single wire wound and Very compact design.
• Inductance Range:0.106mH to 33.75mH. Custom values are welcomed.
• Lower core loss, lower distributed capacitance.
• Coil mount on UL94-V0 rated plastic header.
• Fixed pin spacing allow easy PCB insertion.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
• Single wire wound and Very compact design.
• Inductance Range:0.106mH to 33.75mH. Custom values are welcomed.
• Lower core loss, lower distributed capacitance.
• Coil mount on UL94-V0 rated plastic header.
• Fixed pin spacing allow easy PCB insertion.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
| Teilenummer | Height (mm) Max | Dimension L (mm) Max | Dimension W (mm) Max | Description | Herunterladen | ||
|---|---|---|---|---|---|---|---|
| 55 | 53.5 | 26.5 | 4500uH, 20%, 640 mOhm DCR, 2.5A DIP Torroid Inductor | Data Sheet | |||
| 55.7 | 54 | 28.2 | 33750uH, 20%, 3480 mOhm DCR, 0.95A DIP Torroid Inductor | Data Sheet | |||
| 55 | 53.5 | 26.5 | 1634uH, 20%, 186 mOhm DCR, 4.2A DIP Torroid Inductor | Data Sheet | |||
| 55 | 53.5 | 26.5 | 165uH, 20%, 23.5 mOhm DCR, 13A DIP Torroid Inductor | Data Sheet | 3D Step File | ||
| 55.7 | 54 | 28.2 | 1000uH, 20%, 88 mOhm DCR, 5.4A DIP Torroid Inductor | Data Sheet | |||
| 52.5 | 54.5 | 25.5 | 106uH, 20%, 12.5 mOhm DCR, 16A DIP Torroid Inductor | Data Sheet |
