BL2611 系列
• Ferrite based SMD Drum inductor.
• Inductance range of 1.0uH to 1,000.0uH, Custom values are welcomed
• High current output chokes, up to 2.90A with 10% roll off.
• Low profile 2.92mm max height
• 6.60mm x 4.45mm Max foot print.
• Operating temperature range of -55.0 °C up to +130.0°C.
• RoHS and HF Compliant.
• Tape and Reel quantities: 2,500pcs, Reel
• Inductance range of 1.0uH to 1,000.0uH, Custom values are welcomed
• High current output chokes, up to 2.90A with 10% roll off.
• Low profile 2.92mm max height
• 6.60mm x 4.45mm Max foot print.
• Operating temperature range of -55.0 °C up to +130.0°C.
• RoHS and HF Compliant.
• Tape and Reel quantities: 2,500pcs, Reel
| 零件编号 | Length (mm) Max | Height (mm) Max | Dimension W (mm) Max | Description | 下载 | |
|---|---|---|---|---|---|---|
| 6.6 | 2.92 | 4.45 | 8.2uH, 20%, 160mOhm, 1.55Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 6.8uH, 20%, 130mOhm, 1.6Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 680uH, 20%, 9,200mOhm, 0.19Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 68uH, 20%, 860mOhm, 0.6Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 4.7uH, 20%, 90mOhm, 1.9Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 470uH, 20%, 5,060mOhm, 0.26Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 47uH, 20%, 640mOhm, 0.7Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 3.3uH, 20%, 80mOhm, 2.2Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 330uH, 20%, 3,800mOhm, 0.3Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 33uH, 20%, 510mOhm, 0.8Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 2.7uH, 20%, 80mOhm, 2.45Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 2.2uH, 20%, 70mOhm, 2.55Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 220uH, 20%, 3,110mOhm, 0.31Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 22uH, 20%, 370mOhm, 0.95Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 1.5uH, 20%, 60mOhm, 2.65Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 1uH, 20%, 50mOhm, 2.9Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 150uH, 20%, 2,000mOhm, 0.39Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 15uH, 20%, 230mOhm, 1.25Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 1,000uH, 20%, 13,800mOhm, 0.15Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 100uH, 20%, 1,270mOhm, 0.5Amp Max. SMD Drum Inductor | Data Sheet | ||
| 6.6 | 2.92 | 4.45 | 10uH, 20%, 160mOhm, 1.5Amp Max. SMD Drum Inductor | Data Sheet |
