SLNR4330 Serie
• Miniature SMD shielded power inductor.
• Low profile 3.0mm max height
• Inductance range of 0.91uH to 120.0uH.
• Ideal for DC to DC power converter application.
• Operating temperature range of -55.0 °C up to +130.0°C.
• RoHS and HF compliant.
• Tape and Reel quantities: 2,000pcs, 13” Reel.
• Low profile 3.0mm max height
• Inductance range of 0.91uH to 120.0uH.
• Ideal for DC to DC power converter application.
• Operating temperature range of -55.0 °C up to +130.0°C.
• RoHS and HF compliant.
• Tape and Reel quantities: 2,000pcs, 13” Reel.
| Numero di parte | Length (mm) Max | Height (mm) Max | Dimension W (mm) Max | Description | Scarica | |
|---|---|---|---|---|---|---|
| 4.3 | 3 | 4.3 | 1uH, 30%, 14mOhm, 5.26Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 0.91uH, 30%, 10mOhm, 6.25Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 9.1uH, 20%, 95mOhm, 2Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 91uH, 20%, 1100mOhm, 0.65Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 8.2uH, 20%, 90mOhm, 2.1Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 82uH, 20%, 1,060mOhm, 0.66Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 7.5uH, 20%, 85mOhm, 2.2Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 75uH, 20%, 1,020mOhm, 0.7Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 6.8uH, 20%, 90mOhm, 2.75Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 6.2uH, 20%, 70mOhm, 2.5Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 68uH, 20%, 700mOhm, 0.75Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 62uH, 20%, 585mOhm, 0.8Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 5.6uH, 20%, 65mOhm, 2.6Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 56uH, 20%, 555mOhm, 0.85Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 51uH, 20%, 470mOhm, 0.9Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 4.7uH, 20%, 60mOhm, 2.9Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 4.3uH, 20%, 55mOhm, 2.95Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 47uH, 20%, 445mOhm, 0.95Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 43uH, 20%, 440mOhm, 1Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 3.3uH, 20%, 40mOhm, 3.3Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 39uH, 20%, 435mOhm, 1.03Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 36uH, 20%, 335mOhm, 1.05Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 33uH, 20%, 330mOhm, 1.1Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 2.2uH, 30%, 30mOhm, 4.9Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 22uH, 20%, 225mOhm, 1.3Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 1.8uH, 30%, 25mOhm, 5.4Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 1.5uH, 30%, 20mOhm, 4.84Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 1.2uH, 30%, 15mOhm, 5.8Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 18uH, 20%, 200mOhm, 1.4Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 15uH, 20%, 190mOhm, 1.65Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 120uH, 20%, 1,350mOhm, 0.55Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 12uH, 20%, 135mOhm, 1.7Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 100uH, 20%, 1,150mOhm, 0.6Amp Max. SMD Shielded Drum Inductor | Data Sheet | ||
| 4.3 | 3 | 4.3 | 10uH, 20%, 100mOhm, 1.95Amp Max. SMD Shielded Drum Inductor | Data Sheet |
