- DIP
L201219 シリーズ
• Alloy Powder based DIP Inductor with lower core loss.
• Single wire wound and Very compact design.
• Inductance Range: 0.0402mH to 11.36mH. Custom values are welcomed.
• Lower core loss, lower distributed capacitance.
• Coil mount on UL94-V0 rated plastic header.
• Fixed pin spacing allow easy PCB insertion.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
• Single wire wound and Very compact design.
• Inductance Range: 0.0402mH to 11.36mH. Custom values are welcomed.
• Lower core loss, lower distributed capacitance.
• Coil mount on UL94-V0 rated plastic header.
• Fixed pin spacing allow easy PCB insertion.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
| 部品番号 | Height (mm) Max | Dimension L (mm) Max | Dimension W (mm) Max | Description | ダウンロード | ||
|---|---|---|---|---|---|---|---|
| 37.5 | 33.5 | 20 | 836.7uH, 20%, 80 mOhm DCR, 5.2A DIP Torroid Inductor | Data Sheet | |||
| 37.5 | 33.5 | 20 | 62.8uH, 20%, 9.1 mOhm DCR, 17A DIP Torroid Inductor | Data Sheet | |||
| 32 | 34.5 | 17 | 40.2uH, 20%, 4.8 mOhm DCR, 24A DIP Torroid Inductor | Data Sheet | |||
| 37.5 | 33.5 | 20 | 251.2uH, 20%, 28 mOhm DCR, 9A DIP Torroid Inductor | Data Sheet | 3D Step File | ||
| 37.5 | 33.5 | 20 | 1970uH, 20%, 195 mOhm DCR, 3.3A DIP Torroid Inductor | Data Sheet | |||
| 37.5 | 33.5 | 20 | 11360uH, 20%, 1250 mOhm DCR, 1.2A DIP Torroid Inductor | Data Sheet |
