DCM181320V 系列
• 18.5×13.5mm Max.(L×W), 20.5mm Max. Height.
• Inductance range: 0.70mH～39.0mH, Custom values are welcomed.
• Ideally used as AC common mode noise filter for TV, VCR, switch mode power supply, inverter, industrial equipment, attenuation and control unit
• with better characteristics in low frequency band.
• Dielectric strength: 1500Vrms, winding to winding.
• UL Class B Compliant Common Mode Chokes.
• Two PCB Layouts (V1 & V2) for customer consideration.
• Operating temperature: -55 to +130
• Inductance range: 0.70mH～39.0mH, Custom values are welcomed.
• Ideally used as AC common mode noise filter for TV, VCR, switch mode power supply, inverter, industrial equipment, attenuation and control unit
• with better characteristics in low frequency band.
• Dielectric strength: 1500Vrms, winding to winding.
• UL Class B Compliant Common Mode Chokes.
• Two PCB Layouts (V1 & V2) for customer consideration.
• Operating temperature: -55 to +130
| 零件編號 | Height (mm) Max | Dimension L (mm) Max | Dimension W (mm) Max | Description | 下載 | |
|---|---|---|---|---|---|---|
| 20.5 | 18.5 | 13.5 | 700uH, 30%, 27 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 6800uH, 30%, 280 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 39000uH, 30%, 1700 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 3300uH, 30%, 140 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 27000uH, 30%, 1200 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 2200uH, 30%, 90 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 15000uH, 30%, 780 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 10000uH, 30%, 500 mOhm DCR, DIP Common Mode Choke | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 1000uH, 30%, 55 mOhm DCR, DIP Common Mode Choke | Data Sheet |
