AIFN13A 系列
• Designed for use with Infineon® DrBlade.
• Ferrite based SMD Inductor with lower core loss.
• Inductance Range:100.0nH to 150.0nH. Custom values are welcomed.
• High current output chokes, upto 31.0 Amp with approx. 20% roll off.
• Low Profile 3.30mm Max. height.
• Foot Print 9.40 x 6.70 mm Max.
• Perfect for high density designs with limited board space.
• Saves 50% of application board area when compared to standard design approach.
• Operating frequency up to 2.0 MHz.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliant.
• T & R Qtys: 1500 pcs , 13'' Reel.
• Ferrite based SMD Inductor with lower core loss.
• Inductance Range:100.0nH to 150.0nH. Custom values are welcomed.
• High current output chokes, upto 31.0 Amp with approx. 20% roll off.
• Low Profile 3.30mm Max. height.
• Foot Print 9.40 x 6.70 mm Max.
• Perfect for high density designs with limited board space.
• Saves 50% of application board area when compared to standard design approach.
• Operating frequency up to 2.0 MHz.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliant.
• T & R Qtys: 1500 pcs , 13'' Reel.
| 零件編號 | Height (mm) Max | Inductance L (uH) | DCR @25℃ (mΩ) | Irms (A) @ΔT 40℃ | Isat2 (A) @25℃ Drop 20% | Isat6 (A) @100℃ Drop 20% | Dimension L (mm) Max | Dimension W (mm) Max | Description | 下載 | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.2 | 0.15 | 0.32 | 35 | 20 | 18 | 9.4 | 6.7 | 0.15uH, 20%, 0.32mOhm, 20Amp Max. SMD Ferrite Inductor | Data Sheet | ||
| 3.2 | 0.12 | 0.32 | 35 | 25.5 | 23 | 9.4 | 6.7 | 0.12uH, 20%, 0.32mOhm, 25.5Amp Max. SMD Ferrite Inductor | Data Sheet | ||
| 3.2 | 0.1 | 0.32 | 35 | 31 | 28 | 9.4 | 6.7 | 0.1uH, 20%, 0.32mOhm, 31Amp Max. SMD Ferrite Inductor | Data Sheet |
