DCN181320V Series
• 18.5×13.5mm Max.(L×W),20.5mm Max. Height.
• Inductance range: 0.70mH～150.0mH,Custom values are welcomed.
• Ideally used as AC common mode noise filter for TV, VCR, Switching power supply, PC＆PC related advice, measurement, attenuation and control unit with better characteristics in low frequency band.
• Dielectric strength:1500Vrms,winding to winding.
• Two PCB layout (V1 or V2) for customer consideration.
• UL Class B Compliance Common Mode Chokes.
• Operating temperature: -40 to +125℃.
• RoHS & HF compliant.
• Inductance range: 0.70mH～150.0mH,Custom values are welcomed.
• Ideally used as AC common mode noise filter for TV, VCR, Switching power supply, PC＆PC related advice, measurement, attenuation and control unit with better characteristics in low frequency band.
• Dielectric strength:1500Vrms,winding to winding.
• Two PCB layout (V1 or V2) for customer consideration.
• UL Class B Compliance Common Mode Chokes.
• Operating temperature: -40 to +125℃.
• RoHS & HF compliant.
| Part Number | Height (mm) Max | Dimension L (mm) Max | Dimension W (mm) Max | Description | Download | |
|---|---|---|---|---|---|---|
| 20.5 | 18.5 | 13.5 | 1,000uH, 30%, 16mOhm, 5.4Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 10,000uH, 30%, 120mOhm, 1.4Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 100,000uH, 30%, 1700mOhm, 0.38Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 15,000uH, 30%, 210mOhm, 1.2Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 150,000uH, 30%, 3300mOhm, 0.24Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 2,200uH, 30%, 33mOhm, 3.5Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 27,000uH, 30%, 410mOhm, 1.1Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 3,300uH, 30%, 52mOhm, 2.5Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 39,000uH, 30%, 620mOhm, 0.9Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 47,000uH, 30%, 840mOhm, 0.75Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 50,000uH, 30%, 850mOhm, 0.7Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 6,800uH, 30%, 89mOhm, 1.8Amp Max. DIP Common Mode Chokes | Data Sheet | ||
| 20.5 | 18.5 | 13.5 | 700uH, 30%, 10mOhm, 6.5Amp Max. DIP Common Mode Chokes. | Data Sheet |
