DCN181713H Series
• 18.0×17.5mm Max.(L×W),13.0mm Max. Height.
• Inductance range: 0.70mH～150.0mH,Custom values are welcomed.
• Nanocrystalline Common Mode Chokes Ideally used for AC circuits, and noise filter for TV and VCR, Switching power supply, PC＆PC related advice, measurement, attenuation and control unit with better characteristics in low frequency band.
• Dielectric strength:1500Vrms, winding to winding.
• 10 x 15mm PCB layout.
• UL Class B Compliance Common Mode Chokes.
• Operating temperature: -40 to +125℃
• RoHS & HF compliant.
• Inductance range: 0.70mH～150.0mH,Custom values are welcomed.
• Nanocrystalline Common Mode Chokes Ideally used for AC circuits, and noise filter for TV and VCR, Switching power supply, PC＆PC related advice, measurement, attenuation and control unit with better characteristics in low frequency band.
• Dielectric strength:1500Vrms, winding to winding.
• 10 x 15mm PCB layout.
• UL Class B Compliance Common Mode Chokes.
• Operating temperature: -40 to +125℃
• RoHS & HF compliant.
| Part Number | Height (mm) Max | Dimension L (mm) Max | Dimension W (mm) Max | Description | Download | ||||
|---|---|---|---|---|---|---|---|---|---|
| 13 | 18 | 17.5 | 1,000uH, 50%, 16mOhm, 5.4Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 10,000uH, 50%, 120mOhm, 1.4Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 100,000uH, 50%, 1,700mOhm, 0.38Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 15,000uH, 50%, 210mOhm, 1.2Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 150,000uH, 50%, 33,00mOhm, 0.24Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 2,200uH, 50%, 33mOhm, 3.5Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 27,000uH, 50%, 410mOhm, 1.1Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 3,300uH, 50%, 52mOhm, 2.5Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 39,000uH, 50%, 620mOhm, 0.9Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 47,000uH, 50%, 840mOhm, 0.75Amp Max. DIP Common Mode Chokes | Data Sheet | |||||
| 13 | 18 | 17.5 | 50,000uH, 50%, 850mOhm, 0.7Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 6,800uH, 50%, 89mOhm, 1.8Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter | ||
| 13 | 18 | 17.5 | 700uH, 50%, 10mOhm, 6.5Amp Max. DIP Common Mode Chokes | Data Sheet | LT Spice | LT Spice | S Parameter |
