AF24245A Series
• Ferrite based SMD inductor with lower core loss
• Inductance Range: 30.0nH to 35.0nH, Custom values are welcomed
• High current output chokes, up to 120.0 Amp with approx. 20% roll off
• Low Profile 6.00 mm Max. height
• Foot Print 6.00 x 5.00 mm Max
• Perfect for high density designs with limited board space
• Operating frequency up to 5.0 MHz application
• Operating Temperature Range -55 ℃to + 130 ℃, RoHS & HF compliance
• T & R Qtys: 750 pcs , 13'' Reel
• Inductance Range: 30.0nH to 35.0nH, Custom values are welcomed
• High current output chokes, up to 120.0 Amp with approx. 20% roll off
• Low Profile 6.00 mm Max. height
• Foot Print 6.00 x 5.00 mm Max
• Perfect for high density designs with limited board space
• Operating frequency up to 5.0 MHz application
• Operating Temperature Range -55 ℃to + 130 ℃, RoHS & HF compliance
• T & R Qtys: 750 pcs , 13'' Reel
| Part Number | Height (mm) Max | Inductance L (uH) | DCR @25℃ (mΩ) | Irms (A) @ΔT 40℃ | Isat2 (A) @25℃ Drop 20% | Dimension L (mm) Max | Dimension W (mm) Max | Description | Download | |
|---|---|---|---|---|---|---|---|---|---|---|
| 6 | 0.035 | 0.185 | 50 | 102 | 6 | 5 | 35.0nH, 15%, 0.185mOhm, 102.0A Max. SMD Power Bead | Data Sheet | ||
| 6 | 0.03 | 0.185 | 50 | 120 | 6 | 5 | 30.0nH, 15%, 0.185mOhm, 120.0A Max. SMD Power Bead | Data Sheet |
