AFA3732 Series

• Ferrite based SMD inductor with lower core loss.
• Inductance Range: 40.0nH to 300.0nH, Custom values are welcomed.
• High current output chokes, up to 210.0 Amp with approx. 20% roll off.
• Low Profile 8.00 mm Max. height .
• Foot Print 9.60 x 6.40 mm Max .
• Perfect for high density designs with limited board space.
• Operating frequency up to 5.0 MHz application.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance .
• T & R Qtys: 600 pcs , 13'' Reel ;
