SL16165 Series
• Ferrite based SMD Inductor with lower core loss.
• Inductance Range:65.0nH to 100.0nH,Custom values are welcomed.
• High current output chokes, upto 30.0 Amp with approx. 20% roll off.
• Low Profile 4.00mm Max. height.
• Foot Print 4.00 x 5.00 mm Max.
• Ideal for Buck Converter, VRM & High Density Board Design.
• Operating frequency up to 1 MHz application.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
• T & R Qtys: 2000 pcs , 13'' Reel.
• Inductance Range:65.0nH to 100.0nH,Custom values are welcomed.
• High current output chokes, upto 30.0 Amp with approx. 20% roll off.
• Low Profile 4.00mm Max. height.
• Foot Print 4.00 x 5.00 mm Max.
• Ideal for Buck Converter, VRM & High Density Board Design.
• Operating frequency up to 1 MHz application.
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
• T & R Qtys: 2000 pcs , 13'' Reel.
| Part Number | Height (mm) Max | Inductance L (uH) | DCR @25℃ (mΩ) | Irms (A) @ΔT 40℃ | Isat2 (A) @25℃ Drop 20% | Dimension L (mm) Max | Dimension W (mm) Max | Description | Download | |
|---|---|---|---|---|---|---|---|---|---|---|
| 4 | 0.1 | 0.33 | 30 | 17.5 | 4 | 5 | 0.1uH, 20%, 0.33mOhm, 17.5Amp Max. SMD Power bead | Data Sheet | ||
| 4 | 0.065 | 0.33 | 30 | 30 | 4 | 5 | 0.065uH, 15%, 0.33mOhm, 30Amp Max. SMD Power bead | Data Sheet |
