- DIP
L201203 Series
• Alloy Powder based DIP Inductor with lower core loss.
• Single wire wound and Very compact design.
• Inductance Range:0.073mH to 30.0mH. Custom values are welcomed.
• Lower core loss, lower distributed capacitance.
• Coil mount on UL94-V0 rated plastic header.
• Fixed pin spacing allow easy PCB insertion
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
• Single wire wound and Very compact design.
• Inductance Range:0.073mH to 30.0mH. Custom values are welcomed.
• Lower core loss, lower distributed capacitance.
• Coil mount on UL94-V0 rated plastic header.
• Fixed pin spacing allow easy PCB insertion
• Operating Temperature Range -55°C to + 130°C , RoHs & HF compliance.
| Part Number | Height (mm) Max | Dimension L (mm) Max | Dimension W (mm) Max | Description | Download | |
|---|---|---|---|---|---|---|
| 45.9 | 20.6 | 44 | 1170uH, 20%, 60.5 mOhm DCR, 1.8A DIP Torroid Inductor | Data Sheet | ||
| 45.5 | 19 | 42.5 | 120uH, 20%, 11.6 mOhm DCR, 5.5A DIP Torroid Inductor | Data Sheet | ||
| 45.9 | 44 | 20.6019 | 2632uH, 20%, 142.57 mOhm DCR, 1.2A DIP Torroid Inductor | Data Sheet | ||
| 45.9 | 44 | 20.6 | 30000uH, 20%, 1930 mOhm DCR, 0.35A DIP Torroid Inductor | Data Sheet | ||
| 45.5 | 42.5 | 19 | 5400uH, 20%, 402 mOhm DCR, 0.85A DIP Torroid Inductor | Data Sheet | ||
| 42 | 18.2 | 43.5 | 73uH, 20%, 6.07 mOhm DCR, 7.2A DIP Torroid Inductor | Data Sheet |
