- DIP
L41200R04 Series
• Open Circuit Inductance (OCL): 47uH Typ at 125KHz,1.0Vrms,0Adc;(Ta=25℃).
• Q Value 62 typical. at 125KHz,1.0Vrms;(Ta=25℃).
• DCR: 0.53Ω Max.;(Ta=25℃).
• 26.4x26.4mm foot print.
• 4.3mm height max..
• Operating temperature: -40℃～+105℃.
• Q Value 62 typical. at 125KHz,1.0Vrms;(Ta=25℃).
• DCR: 0.53Ω Max.;(Ta=25℃).
• 26.4x26.4mm foot print.
• 4.3mm height max..
• Operating temperature: -40℃～+105℃.
